Technical Specifications:
Amperage: 5.5A
Connectivity: Thermo Fisher Connect compatible
Data Outputs: USB and OPC UA (ethernet)
Dimensions (DxWxH): Exterior 24.3 x 49.3 x 21.7 in. (61 x 125.2 x 55.1 cm)
Dimensions (D x W x H): Interior13 x 19 x 12 in. (33 x 48.3 x 30.5 cm)
Display: Touchscreen user interface
Electrical Requirements: 220-230V, 50-60Hz
Exterior Finish: Powder-coated Steel
On-Board Datalogging: Yes
PC Programmability: PC Interface software supported
Sample Loading: Front-loading
Type: Controlled-rate Freezer without Printer
Vial Capacity: <1185
Weight (English): 191 lb.
Cabinet Material: Stainless Steel
Capacity (Metric): 48 L
Certifications/Compliance: CE
Plug Type: CEE 7/7
Temperature Range: -180°C to +50°C
Unit Size: Each
Key Features:
• Enables secure, seamless integration into digital ecosystems for data transfer and remote monitoring, supporting Industry 4.0
• Allows for the execution of validated, highly repeatable freezing profiles critical for cell viability.
• Designed to meet regulatory requirements (e.g., 21 CFR Part 11) with features like audit trails, electronic signatures, and password protection.
• Features like a high-temperature alarm, power failure alarm, and an automatic LN2 refill system protect high-value samples.
• Ease of Use: User-friendly touchscreen interface with pre-set and customizable protocols.
Applications: Applications aligns in controlled-rate cryopreservation of high-value biological samples in cell and gene therapy, vaccine production, and research.
Catalog Numbers:
TSCM48SV – Controlled-rate Freezer without Printer
TSCM34FA – Controlled-rate Freezer with Printer
TSCM34FV – Controlled-rate Freezer with Printer
TSCM34SA – Controlled-rate Freezer with Printer
TSCM34SV – Controlled-rate Freezer with Printer
TSCM48FA – Controlled-rate Freezer with Printer
TSCM48FV – Controlled-rate Freezer with Printer
TSCM48SA – Controlled-rate Freezer without Printer
TSCM17FV – Controlled-rate Freezer with Printer
TSCM17SA – Controlled-rate Freezer without Printer
TSCM17SV – Controlled-rate Freezer without Printer
TSCM17FA – Controlled-rate Freezer with Printer
