Technical Specifications:
Maximum Pressure: Pump: 41 MPa (6000 psi); Eluent Generator: 35 MPa (5000 psi); Conductivity Detector (CD) Flow Cell: 10 MPa (1500 psi); Electrochemical Detector (ED) Cell: 0.7 MPa (100 psi)
Flow Rate: Pump: 0.000 to 10.000 mL/min; Eluent Generator: 0.1 to 3 mL/min
Detector Types: Conductivity Detector (CD), Electrochemical Detector (ED)
Detector Compartment: Thermostatted environment for reproducible, sensitive detection
Column Compatibility: Supports 4 µm particle-size columns for high-resolution separations
Software: Thermo Scientific™ Chromeleon™ Chromatography Data System (CDS)
Dimensions: Compact platform with easy component access
Weight: Approximately 15 kg
Power Requirements: 100–240 V AC, 50–60 Hz autoranging
Key Features:
• Automated Eluent Generation (EG): Eliminates manual eluent preparation, enhancing method reproducibility.
• High-Pressure Operation: Supports up to 6000 psi for faster analysis without compromising data quality.
• Flexible Detection Options: Easily swappable detectors including CD and ED, with compatibility for external detectors like UV-Vis and MS.
• Inert Components: PEEK construction ensures compatibility with corrosive eluents and prevents metal contamination.
• Consumables Monitoring: Integrated device monitors track consumable use and performance
• Intuitive Control: Detachable tablet interface for easy system control and monitoring
• Column Oven: Forced-air column oven regulates temperature from 5°C above ambient to 80°C
• PEEK Viper Fittings: Low dead volume, tool-free installation
Applications: Used for routine ion analysis in water, food and beverage, biofuel, and pharmaceutical industries.
