Technical Specifications:
Maximum Pressure: 35 MPa (5000 psi)
Detector Type: Conductivity Detector
Flow Rate Range: 0.00–5.00 mL/min in 0.01 mL/min increments
Pump Type: Serial dual-piston, microprocessor-controlled constant stroke, variable speed
Temperature Range: Ambient +7°C to 60°C
Software: Chromeleon™ CDS, requires Microsoft® Windows® 10 or 11
Dimensions: 66.1 x 29.2 x 43.2 cm
Weight: 15.3 kg
Power Requirements: 100–240 V AC, 50–60 Hz autoranging
Operating Temperature: 4–40°C
Operating Humidity: 20–80% relative, non-condensing
Control Modes: Full control through Chromeleon CDS software; alternative control through TTL or relay closures; one relay output, two TTL outputs, two assignable TTL inputs
USB Communication Protocol: One USB input; three USB outputs
Key Features:
• Supports up to 5000 psi for efficient separations.
• Advanced single-range digital output with autoranging up to 18,000 μS.
• PEEK components ensure compatibility with corrosive eluents.
• Electronically actuated six-port Rheodyne PEEK injection valve.
• Thermostated conductivity detector for consistent measurements.
• Chromeleon™ CDS simplifies operation and data analysis.
• Automated startup and shutdown routines for convenience.
• Space-saving dimensions suitable for various lab setups.
Applications: Ideal for routine ion analysis in environmental monitoring, water quality testing, and other applications requiring reliable ion chromatography.
Catalog Numbers:
22185-60100 – 35 MPa (5000 psi)
