Heating Mantle Body : Made of Mild Steel

Heating Mantle Material : Glass Fibre Yarn

Mantle Capacity : To hold standard Round Bottom Flasks upto 500ml

Valuable Stirring speed : 750 RPM

Temperature Range: Approx. 400°C

Heating Control : Electronic power regulator

Stir Control : Electric regulator

Dimension : 495 x 246 x 200

Permissible Ambient Temperature : 5- 40 °C

Permissible relative moisture : 80%

Weight : 7.3 Kgs

IP Class : 10

Heating Mantle Combined Unit

with Stirrer 3 Position - Analog

BlackDiamond

  • PU Coated Mild Steel construction
  • Heating Mantle Combined unit made of M. steel
  • ON-OFF knob for heat power control
  • Stir speed control also available
  • Mantle knitted with glass fibre yarn
  • Provides uniform heating to flasks
  • For Round Bottomed Flasks as per DIN - 12347
  • Easy maintenance
  • Long Life
  • Also available with Metallic Stand 1600.EU
Item Code Capacity(ml) Volts Watts No.of Position of Regulator
2300.DNEU.01 100 230 660 3/3
2300.DNEU.02 250 230 660 3/3
2300.DNEU.03 500 230 810 3/3
Item Code Capacity(ml) Volts Watts No.of Position of Regulator
2300.DNUS.01 100 115 660 3/3
2300.DNUS.02 250 115 660 3/3
2300.DNUS.03 500 115 810 3/3

Included Accessories

Item Code Accessories
2000.200.01 Vertical Rod Stainless Steel length 542mm, Ø 9.8 mm
2000.200.02 Horizontal Rod Stainless Steel length 972mm, Ø 9.8 mm
2000.200.03 Boss Head
2000.200.04 Clamp

Single Soxhlet Extraction with Stirrer

Extraction unit metal stand with heating mantle stirrer

Model No.(230V, 50 Hz) Model No.(115V, 60 Hz) Capacity ml (A) Extractor Socket (B) Extactor Cone (C) Flask Cap. Condenser Type Watts No. of position of regulator
1600.DNEU.01 1600.DNUS.01 100 40/38, 45/40 24/29, 29/32 150 & 250 Allihin 170 1/1
1600.DNEU.02 1600.DNUS.02 250 45/40 29/32 500 Allihin 170 1/1
1600.DNEU.03 1600.DNUS.03 500 60/46 29/32 1000 Allihin 220 1/1
