Technical Specifications:
Mass Range: 40 to 6000 m/z
Maximum Resolution: Up to 240,000 at m/z 200
Mass Accuracy: <1 ppm RMS drift over 24 hours with internal lock mass calibration
Scan Rates: Up to 22 Hz at resolution setting of 15,000 at m/z 200
Polarity Switching: One full cycle <700 ms (1.4 Hz)
Dynamic Range: >5000:1 within a single Orbitrap mass analyzer spectrum
Weight: 120 kg (265 lb.) without data system, vacuum rough pumps, and optional items
Analog Inputs: Channel 1 analog input (±10 V), Channel 2 analog input (±10 V)
Key Features:
• Achieves up to 240,000 resolution at m/z 200 for precise identification and quantification.
• Enables rapid analysis by switching between positive and negative modes in less than 700 ms.
• Maintains <1 ppm mass accuracy over extended periods with internal calibration.
• Covers a wide mass range from 40 to 6000 m/z, accommodating diverse analytes.
• Features ready-to-run method templates and a drag-and-drop user interface to accelerate method development.
Applications: Uses aligns in high-throughput screening and quantitation assays in areas such as forensic toxicology, metabolomics, environmental analysis, and peptide mapping.
Catalog Number:
BRE725535
