Technical Specifications:
Radiation Type: Alpha ($\alpha$) and Beta ($\beta$).
Detector Type: Dual-phosphor scintillator.
Sensitive Area: 69 mm x 145 mm [2.71″ x 5.71″].
Window Thickness: 0.87 mg/cm² aluminized plastic film.
Efficiency (per surface emission): Am-241: 36% ($\alpha$); Sr/Y-90: 49% ($\beta$); Co-60: 23% ($\beta$).
Gamma Response (Cs-137): Approx. 40 s⁻¹/(µSv/h) or 0.4 s⁻¹/(µR/h).
Count Rate: 1 to 100K CPS.
Battery Life: >1,000 hours of operation using 2 C batteries (rechargeable NiMH-cells can be used).
Weight (approx.): 0.9 kg (2 lbs).
Dimensions: 355 mm x 100 mm x 180 mm (14″ x 4″ x 7.1″).
Operating Temperature: -20 °C to 50 °C (-4 °F to 122 °F).
Communication: IR port via USB (with optional software).
Key Features:
• Accurately separates alpha and beta signals for precise measurement.
• Offers over 1,000 hours of operation on two C-cell batteries, resulting in low cost of ownership.
• Includes Scaler/Timer (with preset count/time) for sample measurements, Continuous Ratemeter for frisker operation, and $\alpha$, $\beta$, or $\alpha + \beta$ modes.
• Menu-driven user interface with a bright, backlit LCD display and simple five-button control, minimizing training costs.
• Huge internal memory for both scaler-type and continuous data recording (up to 1,200 data sets).
• Users can select the proper calibration factor from a list of isotopes (e.g., Bq, Bq/cm², dpm).
Applications: Primarily aligns in daily surface contamination measurements and regulatory monitoring in environments where alpha and beta radiation is present.
Catalog Number:
4250683
