Technical Specifications:
Cooling capacity: Up to ~1000 W (≈3415 BTU) at 20 °C, 60 Hz
Temperature range: –10 °C to +30 °C (Low-Range model)
Temperature stability: ±0.1 °C typical
Pump/flow options (model dependent): PD1 (Positive Displacement): ~4.5 L/min at ~4.1 bar (50 Hz)
PD2: up to ~9.4 L/min (50 Hz) or ~13.6 L/min (60 Hz) at ~4.1 bar
MDC1 (Mag-drive Centrifugal): ~7.6 L/min at ~0.4 bar
Reservoir volume: Approximately 9.5 L (2.5 gal)
Refrigerant: R134a
Electrical: Available in 115 V/60 Hz or 230 V/50 Hz models
Construction: Air-cooled refrigeration system with digital control interface
Key Features:
• Integrated full-flow fluid strainer to maintain clean circulating fluid
• Reduced plumbing connections to minimize leaks and simplify setup
• Digital temperature controller with alarms for precise monitoring
• Front pressure gauge for quick system performance checks
• Top fill port for easy filling and maintenance
• Locking casters for easy movement and stability
• Multiple pump configurations to meet various pressure and flow demands
Applications: Used for precise temperature control in laboratory instruments, reactors, analytical systems, and pilot-scale processes.
Catalog Number:
197221010000
