Technical Specifications:
Access Security: Key lock
Capacity (English) Shelf: 100 lb.
Capacity (Metric) Shelf: 45 kg
Casters: Yes, customer installed
Defrost: Automatic
Dimensions (DxWxH) Exterior: 75.7 x 32 x 81 in. (1924 x 813 x 2057 mm)
Dimensions (D x W x H) Interior: 72 x 28.5 x 61.75 in. (1829 x 724 x 1569 mm)
Display: Digital
Electrical Requirements: 120 V/60 Hz
Ports: 1 rear access port
Refrigerant: R290
Shipping Weight (English): 730 lb.
Shipping Weight (Metric): 318 kg
Temperature (Setpoint): 5°C
Cabinet Material: Stainless Steel
Capacity (English): 72 cu. ft.
Capacity (Metric): 2038 L
Certifications/Compliance: cULus
Compressor: Bottom-mounted
Door Style: Glass Self-closing with Lock
Exterior Finish: Stainless Steel
Monitoring Options: SMART VUE Compatible, Remote Alarm Contacts
No. of Doors: 3
Plug Type: 3
Shelves: 12 Adjustable
Style: 318 kg
Temperature Range: 4°C to 6°C
Unit Size: Each
Key Features:
• 72 cu ft (≈ 2 038 L) interior capacity.
• Temperature range nominally 4 °C to 6 °C (setpoint ~5 °C).
• Three self‑closing glass swing doors with key lock option.
• Digital controller with adjustable setpoint, high/low temperature alarms, and door‑ajar alarm.
• Remote alarm contacts and SMART VUE compatibility for monitoring.
• Refrigerant R290 (hydrocarbon, SNAP‑compliant) for lower environmental impact.
• Twelve adjustable shelves (full size) rated ~100 lb. (≈ 45 kg) per shelf.
• Durable cabinet (painted steel or optional stainless‑steel) with automatic defrost.
• External dimensions approx. 75.7″ D × 32″ W × 81″ H (1924×813×2057 mm).
Applications: Ideal for laboratories, research facilities, clinical settings, or industrial labs needing large‑volume, controlled‑temperature storage of reagents, media, culture materials, or non‑critical samples (~4‑6 °C).
Catalog Numbers:
TSV72RSGA – Stainless Steel
TSV72RPGA – Painted Steel
