Technical Specifications:
Flow range (nano mode): 50 nL/min – 50 µL/min
Extended flow range: up to 2,500 µL/min with micro pump configuration
Maximum pressure: up to 900 bar (nano mode)
System delay volume: <350 nL in pre-concentration setup
Retention time reproducibility: ≤0.2% RSD over 30-min gradients
pH range: 2 – 10
Wetted materials: MP35N, titanium, PEEK, PTFE, FEP, sapphire, zirconia, alumina, fused silica, stainless steel, PCTFE, FFKM elastomer
Optional UV/Vis detection: up to 200 Hz data rate; flow-cell volumes from 3 nL to 180 nL
Key Features:
• ProFlow™ technology ensures ultra-stable, precise flow control for exceptional retention-time reproducibility.
• Supports nano, capillary, and micro flow regimes, offering maximum flexibility for diverse applications.
• nanoViper™ fingertight fittings simplify setup and minimize dead volume for improved chromatographic performance.
• Dual-pump architecture supports pre-concentration, trap/elute, and 2D-LC workflows.
• Seamless integration with Thermo Scientific mass spectrometers and Chromeleon™ software for full system control.
• Delivers high-resolution, high-pressure capability, and low gradient delay volumes for sensitive LC-MS analyses.
Applications: Used for high-sensitivity LC-MS workflows in proteomics, metabolomics, and biopharmaceutical research requiring ultra-precise nano- and micro-flow separations.
Catalog number:
TRSLBOP
